Universal AHD 1080P Front Camera Windshield Mount Adjustable Viewing Angle ADAS System for Trucks Buses

30pts
MOQ
Negotiation
Price
Universal AHD 1080P Front Camera Windshield Mount Adjustable Viewing Angle ADAS System for Trucks Buses
Features Gallery Product Description Request A Quote
Features
Specifications
Highlight:

AHD 1080P front camera

,

windshield mount adjustable angle

,

ADAS camera for trucks buses

Basic Infomation
Place of Origin: China
Brand Name: KINGCROWN
Certification: ROHS
Payment & Shipping Terms
Packaging Details: Export standard package
Delivery Time: 45 days
Payment Terms: L/C,T/T
Supply Ability: 1000sets/month
Product Description
Product Overview

This universal AHD 1080P front camera is purpose-built for windshield installation and integrates seamlessly with ADAS systems on trucks and buses. Its adjustable viewing angle captures accurate forward road information for ADAS algorithm processing. With stable AHD signal transmission, it connects smoothly to MDVR and ADAS hosts, enabling lane departure warning and forward collision alerts that significantly enhance active driving safety for long-distance fleets and urban shuttle operations.

Key Selling Points
  • AHD 1080P high-definition image output delivers clear forward road vision for reliable ADAS analysis.
  • Windshield adhesive mount design keeps interior installation neat without drilling body panels.
  • Flexible adjustable lens bracket allows users to fine-tune the viewing angle to specific requirements.
  • Compatible with mainstream ADAS modules, supporting forward collision and lane departure warning.
  • Wide 12V–24V voltage range fits most trucks, buses, and heavy-duty commercial vehicles.
  • Anti-reflection shell reduces windshield glare and guarantees stable imaging during daytime driving.
Technical Specifications
Product Type Windshield Mount Front ADAS Camera
Camera Resolution AHD 1080P
View Angle 120° Adjustable Wide Angle
Night Vision Starlight Low-light Night Vision
Waterproof Rating IP65
Voltage DC 12V–24V
Lens Anti-glare HD Optical Lens
Screen Size No built-in screen; works with ADAS host & MDVR
Wired or Wireless Wired, AHD signal
Working Temperature -20℃ ~ +70℃
Vehicle Compatibility Truck, Bus, Heavy Commercial Vehicle
Feature Highlights
360° Surround Monitoring

This forward ADAS camera works together with rear and side cameras to form a complete vehicle surround monitoring system, providing reliable forward video data and full-perimeter vision protection for large commercial vehicles.

High-Definition Night Vision

Equipped with a starlight-sensitive sensor, the camera maintains distinguishable forward road images under dim light. It avoids infrared reflection on the windshield and supplies valid image data for ADAS identification at night.

Waterproof and Dustproof Housing

The compact sealed casing reaches IP65 protection grade, resisting dust and occasional moisture inside the cab while maintaining stable operation in the complex temperature and humidity environment of the vehicle cabin.

Smart Multi-View Auto Switching

When matched with a supporting MDVR and ADAS system, the front view channel can be displayed independently or switched together with side and rear views. It supports automatic pop-up alarm pictures when an ADAS risk warning triggers.

Suitable for Heavy-Duty and Commercial Vehicles

Wide voltage input, anti-vibration structure, and windshield hidden installation are customized for trucks and buses. It is a preferred safety upgrade solution for logistics fleets, passenger bus companies, and commercial vehicle refitting projects.
