4PIN 1080P Vehicle Backup Camera AHD 2053 Chip IR Night Vision Waterproof 12 24V for Truck MDVR Monitoring System

Product Description

4PIN 1080P Vehicle Backup Camera with AHD 2053 Chip

This professional 4PIN AHD 1080P vehicle backup camera features a high-performance 2053 CMOS image chip, delivering crystal-clear 1080P high-definition video with advanced 3D digital noise reduction. Designed specifically for truck MDVR monitoring systems, it provides reliable visual monitoring for fleet management and vehicle refitting projects.

Key Features

High-performance 2053 CMOS chip for AHD 1080P clear imaging with 3D noise reduction
Standard 4PIN aviation connector for plug-and-play installation with truck MDVR systems
Built-in IR infrared LED lights for reliable night vision performance
IP68 waterproof sealed housing for long-term exterior vehicle installation
DC12-24V wide voltage compatibility for various heavy-duty trucks
Shockproof metal bracket structure withstands continuous vibration

Technical Specifications

Category	Specification
Product Type	AHD Truck Backup Camera
Image Chip	GC2053 CMOS Chip
Resolution	AHD 1080P
Night Vision	IR Infrared LED Night Vision
Waterproof Rating	IP68
Working Voltage	DC12-24V
Connector	4PIN Aviation Connector
Lens	Wide Angle Glass Lens
Working Temperature	-30℃ ~ +70℃
Matching Device	Truck MDVR / Mobile DVR
Applicable Vehicle	Heavy-duty Trucks
Installation	Rear view exterior mounting

Advanced Technology Features

High-performance GC2053 CMOS Image Chip

The camera utilizes a mature GC2053 CMOS sensor supporting AHD 1080P high-definition output. Built-in 3D noise reduction algorithm effectively suppresses image noise in low-light environments, delivering cleaner and smoother pictures compared to ordinary camera chips. This technology ensures accurate color reproduction and clear detail capture for road obstacles, vehicle outlines, and road markers.

Standard 4PIN Aviation Connector for MDVR Matching

Features an industry-universal 4PIN aviation plug interface that integrates video signal and power supply in one cable. The anti-loosening locking design prevents poor contact caused by vehicle vibration during long-distance transportation, simplifying on-site wiring work for fleet refitting and reducing signal interruption issues.

IR Infrared LED Night Vision for Low-light Monitoring

Built-in infrared LED lights automatically activate when ambient light drops below threshold. In pitch-black nights, dim warehouses, or underground parking scenarios, it generates clear monitoring images to help drivers identify pedestrians, barriers, and rear vehicles. Optimized infrared lamp layout prevents local overexposure, ensuring balanced image brightness for reversing safety.

IP68 Fully Sealed Waterproof & Dustproof Housing

The camera shell features fully sealed IP68 waterproof construction with internal circuit boards coated with conformal coating for moisture-proof, anti-corrosion, and anti-salt spray protection. It withstands heavy rain, mud splashing, and high-pressure water washing during truck maintenance, effectively preventing water and dust intrusion in harsh outdoor environments.

12-24V Wide Voltage & Surge Protection Circuit

Wide DC12-24V input voltage design ensures compatibility with most heavy-duty trucks. Built-in reverse polarity protection and surge suppression chip filter instantaneous voltage spikes and current fluctuations generated during engine starts and stops, preventing chip burnout and ensuring continuous stable operation across mixed fleet projects.

Heavy-duty Shockproof Mounting Bracket

Equipped with a sturdy metal adjustable bracket featuring internal shock absorption structure to absorb continuous jolts and vibrations from rough, uneven roads. The adjustable bracket allows users to freely fine-tune monitoring angles according to installation position, eliminating rear blind spots for large trucks and improving reversing safety.
